Automatic Solar Cell IV Sorting Integrated Tester

Technical specifications:

Parameters:

Features:

1. Solar cell tester is a high-reliability, high-precision solar battery test equipment.
2. The equipment adopts high-power, long-life imported pulses xenon lamp as the simulator light source;
3. Imported ultra-high-precision four-channel synchronous data acquisition card to test data acquisition;
4. Professional superlinear electronic load ensure the test results are accurate;

5. Non contact detection to avoid secondary damage of battery.

Application:

Suitable for solar PV panel manufacturers to sort and analytic test solar panels.

Environmental Requirements:

1. Solar panel tester venue requires greater than 3m×6m; higher than 2.5m special testing room; room illumination is less than 100 lux;

2. Room should be installed heating and air conditioning, indoor temperatures should be stable at around 25 ℃;

3. Power with 220v/2kw, and convenient connection, pay special attention to ensure that the equipment can be reliably grounded;

4. To ensure that the battery is tested under essentially the same conditions as at room temperature, there must be a sufficient area of the test battery connected temporarily to the test chamber.

5. The test room shall be equipped with a compressed air source interface, the air pressure of the air source should be stable at 5 - 8 Kg/c㎡.
